| Display Method |
VFD 20*2 (green or Blue) |
| Number of characters |
40(20columns x 2 lines) |
| Brightness |
500~1000 cd/m2 |
| Character font |
5×7 dot matrix |
| Character type |
95 Alphanumeric |
| Dot Size (X x Y) |
5.25 (W) x9.02 (H)mm |
| Panel Dimension |
220(W) x 45(D) x 125(H)mm |
| Pole Dimension |
Per support length: 140(L) x 34.5(Dia)mm |
| Base Dimension |
205(W) x 106(D) x 33(H)mm |
| Viewing Angle |
Max. 90° |
| Horizontal Rotation |
Max. 355° |
| Weight |
Approx. 980 grams |
| Commands Mode |
LD220, EPSON POS D101, AEDEX, UTC/S, UTC/P, ADM788, DSP800, CD5220, EMAX, LOGIC CONTROL |
| Language Support |
FRANCE、GERMANY、U.K、DENMARKI、SWEDEN、ITALY、SPAIN、JAPAN、NORWAY、DENMARKII、SLAVONIC、RUSSIA、Portuguese、Canadian French、Nordic、Turkish、Greek、West European Latin |
| Interface |
RS-232(serial) / USB |
| Connection / Baud rate |
Direct connection 9600 or 19,200 bps |
| Reliability / MTBF |
30,000 hours |
| Power |
5~24 VDC |
| EMC standards |
FCC, CE |
