| Printing |
Print Method |
Direct Thermal |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
Max.100mm/s |
| Print Width |
48 mm |
| Interface |
USB, Bluetooth3.0/4.0 |
| Power Saving |
Sleep Mode |
YES |
| Memory |
RAM |
4 MB |
| Flash |
8 MB |
| Programming Language |
ESC/POS |
| Fonts |
Alphanumeric; Simplified Chinese, Traditional Chinese; 42 International Character Sets |
| Barcode |
Linear Barcodes |
UPC-A, UPC-E, EAN-8, EAN-13, CODE39, ITF, CODEBAR, CODE 128, CODE 93 |
| 2D Barcodes |
PDF417, QR Code |
| Graphics |
Support bitmap printing with different density and user defined bitmap printing |
| Interface |
Standard |
MicroUSB, Bluetooth 3.0/4.0 |
| Option |
N/A |
| Sensors |
Standard |
Paper out Detector, Cover open Detector, Black mark Detector, Gap Detector |
| Option |
N/A |
| LED indicator |
Power |
Green |
| Error |
Red |
| Power |
Input |
AC 100 ~ 240 V, 50/60 Hz |
| Output |
DC 5V, 1A |
| Battery |
7.4V rechargeable Li-polymer battery, 1300mAh |
| Paper |
Type |
Continuous paper with or with black mark, Linerless label, Roll-fed Label |
| Width |
58 mm |
| Thickness |
0.053 ~ 0.13 mm |
| Diameter of Paper Roll |
Max. Φ40 mm (O.D) |
| Paper Loading |
Easy loading mechanism |
| Physical Characteristics |
Working Condition |
-5°C ~ 50°C, 25% ~ 85% R.H, no-condensing |
| Storage Condition |
-30°C ~ 60°C, 5% ～ 95% R.H, no-condensing |
| Dimension |
126.9(L)×84.4(W)×50.6(H) mm |
| Weight |
0.234 kg |
| Options and Accessories |
Protective Cover case, USB Cable, Belt Clip, Docking Cradle, Paper Roll, Quick Start Guide, CD |
| Software |
Driver |
Windows XP/ Vista/ 7/ 8/ 10; Linux; iOS |
| SDK |
WinCE, Windows Mobile, Android |
