| Printing Method |
Direct Thermal & Thermal Transfer |
| Printing Resolution |
203 dpi(8 dots/mm) |
| Printing Speed |
Max. 5 ips |
| Printing Length |
Max. 100”(2540mm) / Min 0.2” (5mm) |
| Printing Width |
Max. 4.1”(104mm) |
| Memory |
8MB DRAM, 4MB Flash ROM |
| CPU Type |
32 bit RISC microprocessor |
| Sensors |
Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Center fixed) |
| Operation Interface |
LED Indicator x 2, Botton(Feed) x 1 |
| Communication Interface |
USB device, RS-232, Parallel |
| Fonts |
Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24×24 4 direction 0° ~ 270° rotation Soft fonts are downloadable |
| Wireless Security |
N/A |
| 1D Barcodes |
Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128 UCC/EAN-128 K-MART, UCC/EAN-128 Random Weight, Telepen, FIM, Interleave 2 of 5 (Standard/with modulo 10 checksum/with human readable check digit/with modulo 10 checksum & shipping bearer bars), GS1 Data bar (RSS) |
| 2D Barcodes |
PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 only), QR code, Composite codes |
| Graphics |
PPLA: PCX, BMP, IMG and HEX format files PPLB: PCX and Binary raster, BMP and GDI |
| Emulation |
PPLA, PPLB |
| Software-label Editing |
Windows Driver (Windows XP/Vista/Win7/Win8/Win10), BarTender® from Seaguall Scientific |
| Windows Compatibility |
N/A |
| Software-utility |
Printer Utility, Font Utility |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
| Media |
Max. width 4.3”(110mm) Min. width 1” (25.4 mm) Thickness 0.0025”~0.01” (0.0635mm ~0.254mm) Max. roll capacity (OD): 5″(127 mm) Core size 1”(2.54mm) Max. roll capacity (OD): 4.5″(114.3 mm) Core size 0.5”(12.7mm) Optional Max. roll capacity (OD): 4.7″(120 mm) Core size 1.5”(38.1mm) Optional |
| Ribbon |
Ribbon roll – Max. OD: 2.6”(67mm) Ribbon Length: Max. 300m Core size – ID: 1”(2.54mm) Ribbon Width:1″~4.33″(25.4mm~110mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect) |
| Drop Resistance |
N/A |
| Printer Dimensions |
W 225mm x H 186mm x D 273mm |
| Printer Weight |
2.1 kgs |
| Power Source |
Universal Switching Power Supply AC Input: 100V~240V, 1.8A, 50~60Hz, DC Output: 24V 2.4A |
| Battery |
N/A |
| Operation Environment |
Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) |
| Real Time Clock |
N/A |
| Standard Item |
N/A |
| Optional Items |
Guillotine-Full Cutter / Partial Cutter, Rotary Cutter, RTC card, External media stand |
| Agency Listing |
CE, FCC, cTUVus, CCC, RoHS, BSMI |
| Attention |
*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. |
