| Printing Method |
Direct Thermal |
| Printing Resolution |
203 dpi(8 dots/mm) |
| Printing Speed |
Max. 7 ips |
| Printing Length |
Max. 100”(2540mm) |
| Printing Width |
Max. 2.13”(54 mm) |
| Memory |
32 MB SDRAM, 16MB Flash ROM (USB storage up to 32GB) |
| CPU Type |
32 bit RISC microprocessor |
| Sensors |
Reflective sensor x 1 (movable) & Transmissive sensor x 1 (fixed, 6.27mm offset) |
| Operation Interface |
LED Indicator x 2, Botton(Feed) x 1 |
| Communication Interface |
USB device, USB host |
| Fonts |
Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24×24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily Support scalable font |
| Wireless Security |
N/A |
| 1D Barcodes |
UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked |
| 2D Barcodes |
QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode |
| Graphics |
PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI |
| Emulation |
PPLA, PPLB, PPLZ |
| Software-label Editing |
Windows Driver (Windows Vista/Win7/Win8/Win10), BarTender® from Seaguall Scientific |
| Windows Compatibility |
N/A |
| Software-utility |
Printer Tool |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket or plain paper label |
| Media |
Max. width 60mm. Min. width 12mm. Media thickness: 0.06~0.2mm 5”(127mm) OD on a 1”/1.5” (25.4/38 mm) ID core; 4.5”(114mm) OD on a 0.5” (12.7mm) ID core. |
| Ribbon |
N/A |
| Drop Resistance |
N/A |
| Printer Dimensions |
W 116mm x H 170mm x D 215mm |
| Printer Weight |
1.05 kgs |
| Power Source |
Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 2.4A |
| Battery |
N/A |
| Operation Environment |
Operation Temperature: 40°F~104°F (4°C~40°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C) |
| Real Time Clock |
N/A |
| Standard Item |
N/A |
| Optional Items |
Guillotine-Full Cutter / Partial Cutter, Dispenser , Bluetooth, WLAN, RS-232, Ethernet |
| Agency Listing |
CE, FCC, TUV/cTUVus, Energy Star, CCC, RoHS, BSMI |
| Attention |
*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. |
