Technical Specification |
| Dimensions: |
180mm x 95mm x 70mm |
| Weight: |
212g |
| Voltage Current: |
5 VDC +/-10% @ 500 mA |
|
|
|
Performance Characteristics |
| Image (Pixels): |
640 pixels (H)x 480 pixels (V) |
| Light Source: |
Aiming: 617 nm LED; illumination: 6500K LED |
| Field of View: |
45° (H) x 35° (V) |
| Roll / Pitch / Yaw: |
360°, ±65°, ±60° |
| Battery volume |
4.2v/2500mAh |
| Charging time |
5-6 h |
| Working time |
Scan once every 1 second and work continuously for 18 hours. (new battery, full charge) |
| Wireless technology |
Bluetooth 4.0 |
| Operation distance |
100 meters (open space) |
| Print Contrast: |
25% minimum reflective difference |
| Interfaces Supported: |
USB, RS232 |
| Motion Tolerances |
up to 25 in. (63.5 cm) per second |
|
|
|
Symbology Decode Capability |
| 1-D: |
UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc. |
| 2-D: |
PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc. |
|
|
|
User Environment |
| Operating Temperature: |
0°C to 50°C |
| Storage Temperature: |
-40°C to 70°C |
| Humidity: |
0% to 95% relative humidity, non-condensing |
| Shock Specifications: |
Designed to withstand 1.5m(5’) drops |
| Ambient Light Immunity: |
100.000 Lux. |
|
|
|
Decode Ranges |
| 5 mil (Code 39) |
50mm-110mm |
| 13 mil (100% UPCA) |
30mm-300mm |
| 1D Minimal Resolution |
4mil |
