Physical Characteristics |
| Dimensions: |
83mm x 80mm x 147mm |
| Weight: |
133g |
| Voltage: |
3.3-5 VDC |
| Current: |
200mA (Operating) |
|
|
|
Performance Characteristics |
| Light Source: |
Illumination: 6500K LED |
| Field of View: |
72° (H) x 64° (V) |
| Roll / Pitch / Yaw: |
360°, ±65°, ±60° |
| Print Contrast: |
20% minimum reflective difference |
| Interfaces Supported: |
USB, RS232 |
|
|
|
Symbology Decode Capability |
| 1-D: |
UPC, EAN, Code128, Code 39, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc. |
| 2-D: |
PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin,etc. |
| Minimum Resolution |
>3.9 mil Code39 |
|
|
|
User Environment |
| Operating Temperature: |
-30°C to 70°C |
| Storage Temperature: |
-40°C to 70°C |
| Humidity: |
0% to 95% relative humidity, non-condensing |
| Shock Specifications: |
Designed to withstand 1.5m (5’) drops |
| Ambient Light Immunity: |
100.000 Lux. |
|
|
|
Decode Ranges |
| 10 mil (Code 39) |
0mm-50mm |
| 13 mil (100%Upca) |
5mm-110mm |
